| Generator Set Specification |
| Model | A-P440
|
| Max. Power | kVA | 440 |
| kW | 352 |
| Rate Power | kVA | 400 |
| kW | 320 |
| Frequency | Hz | 50 |
| Rate Voltage | V | 400/230 |
| Rate Current | A | 577.4 |
| Fuel Tank Capacity | L | 400 |
| Dimension For Open-type Genset | mm | 3500 X 1200 X 1960 |
| Weight For Open-type Genset | kg | 3480 |
| Dimension For Soundproof Genset | mm | 4300 X 1350 X 2250 |
| Weight For Soundproof Generator | kg | 5260 |
| Noise Level for Soundproof Generator at 7M | dBA | 80 |
| Battery for Starting | Two of 180A Free Maintenance Battery |
| Engine Specification |
| Engine Manufacturer | Perkins Engines Company Ltd |
| Engine Brand | Perkins |
| Engine Model | 2206C-E13TAG3 |
| No. of Cylinder | 6 Cylinder in line |
| Aspiration | Turbocharged and Air to Air Aftercooled |
| Governor | Electric |
| Engine Max. Output Power | kW | 413 |
| Displacement | L | 12.5 |
| Compression Ratio | 16.3 : 1 |
| Starting Voltage | V | 24 |
| Bore | mm | 130 |
| Stroke | mm | 157 |
| Lubrication Oil Capacity | L | 38 |
| Intake Air Flow | M3/Min | 12.5 |
| Fuel Consumption at 100% Load | L/H | 85 |
| Alternator Specification |
| Alternator Manufacturer | Cummins Generator Technologies |
| Alternator Model | HCI 444 F |
| Alternator Brand | Stamford |
| Rate Output | kVA | 400 |
| Frequency | Hz | 50Hz |
| Altitude | M | ≤1000 |
| Insulation | Class H |
| Phase | 3 Phase |
| Working Temperature without power decrease | ≤40℃ |
| Working Altitude without power decrease | ≤1000m |
| Automatic Voltage Regulation | KRB440 |
| Protection Grade | IP23 |
| Alternator for optional | Leroy Somer, Marathon, Mecc Alte and Hosem Brushless alternator for optional |
WARRANTY:
We provide manufacturer’s warranty of: 1500 hours or 1 year whichever comes first – effective from date of delivery at client’s site. Warranty policy covers: any manufacturing defects or any premature wear & tear due to usage. Faulty part(s) is/are replaced/repaired within warranty period. Warranty does not cover: improper maintenance by the user, consumable items, servicing by unauthorized person, running the genset above it’s capacity or any unauthorized modification of the genset.
FQA
What is a Generator Set?
A generator set, also known as a genset, is a combination of an engine and an alternator (generator) that converts mechanical energy into electrical energy. It is used to provide backup or primary power supply in case of electrical grid failures or in remote areas without access to the grid.
How Does a Generator Set Work?
The engine of the generator set runs on fuel (such as diesel, natural gas, or gasoline), which drives the alternator to generate electrical power. The power output is measured in kilowatts (kW) or megawatts (MW) and can be used to operate electrical equipment.
What Types of Fuel Can Generator Sets Use?
Generator sets can use various types of fuel, including diesel, natural gas, gasoline, and propane. The choice of fuel depends on factors like cost, availability, and environmental considerations.
What Are the Applications of Generator Sets?
Generator sets are used in various applications, including residential homes, commercial buildings, industries, data centers, hospitals, construction sites, events, and more. They provide backup power to ensure continuous operation in case of power outages.
